Recommended horsepower rating: 550-1000HP
Recommended engine displacement: 2L to 5.5L
Dual ceramic ball bearing
Billet aluminium compressor wheel
Ported shroud compressor housing cover
Speed sensor port included in compressor cover (sold separately, AF8050-1010)
Recommended turbo drain adapter AF463-01 or AF463-05
M14x1.5mm coolant fittings sold separately
External wastegate sold separately
Turbine inlet & outlet flange V-band sold separately (outlet AF8080-1000) (inlet AF8080-1010)
Compressor
Inducer: 67mm
Exducer: 84mm
Extended Tip: 87.5mm
A/R: 0.72
Turbine
Inducer: 68mm
Exducer: 62.3mm
A/R: 1.01
Compressor Inlet: 4" Slip fit
Compressor Outlet: 2.5" Slip fit
Turbine Inlet Flange: V-Band
Turbine Outlet Flange: V-Band
Wastegate: External wastegate
