Recommended horsepower rating: 475-1200HP
Recommended engine displacement: 2L to 7L
Dual ceramic ball bearing
Billet aluminium compressor wheel
Ported shroud compressor housing cover
Speed sensor port included in compressor cover (sold separately, AF8050-1010)
Recommended turbo drain adapter AF463-02 or AF463-06
M14x1.5mm coolant fittings sold separately
External wastegate sold separately
Turbine inlet & outlet flange V-band sold separately
Turbo oil feed plate sold separately AF463-01
Compressor
Inducer: 73mm
Exducer: 91mm
Extended Tip: 96mm
A/R: 0.90
Turbine
Inducer: 82mm
Exducer: 75mm
A/R: 1.28
Compressor Inlet: 5" Slip fit
Compressor Outlet: 3" Slip fit
Turbine Inlet Flange:
Turbine Outlet Flange:
Wastegate: External wastegate
