Recommended horsepower rating: 700-1250HP
Recommended engine displacement: 2L to 8L
Dual ceramic ball bearing
Billet aluminium compressor wheel
Ported shroud compressor housing cover
Speed sensor port included in compressor cover (sold separately, AF8050-1010)
Recommended turbo drain adapter AF463-02 or AF463-06
M18x1.5mm coolant fittings sold separately
External wastegate sold separately
Turbine inlet gasket sold separately AF9557-0003
All V-bands sold separately
Turbo oil feed plate sold separately AF463-01
Compressor
Inducer: 79.8mm
Exducer: 108.4mm
Extended Tip: 113mm
A/R: 0.60
Turbine
Inducer: 88.9mm
Exducer: 77.4mm
A/R: 1.15
Compressor Inlet: 5" Slip fit
Compressor Outlet: V-Band (AF8080-1009)
Turbine Inlet Flange: T4 Twin Entry
Turbine Outlet Flange: V-Band (AF8080-1001)
Wastegate: External wastegate
