OCAM H-Bar, Replacement Winch Bar For Toyota Hilux 08/2020-Current
WARRANTY 2 YEARS
This winch bar comes in black. Colour-coding is available. Please ask one of our team for details.
Are you looking for a hoopless winch bar for your 4WD? If so, you can’t go past the OCAM H-Bar!
A hoopless bar offers significantly enhanced frontal protection over the vehicle's plastic bumper. It makes your vehicle off-road capable and its rigid structure allows for mounting essential offroad accessories such as a winch, driving lights, and UHF antenna.
The OCAM H-Bar is a premium product. It is designed to match the vehicle's shape and lines so that it fits perfectly, protects and enhances the vehicle's appearance.
MANUFACTURING
The OCAM H-Bars are manufactured overseas using quality materials and processes. Our appointed manufacturer is a fully-approved OEM facility that produces a wide range of vehicle accessories for the global automotive market, including various major vehicle manufacturers. All aspects of the manufacturing process are quality controlled and maintained.
CRASH TESTING / ADR COMPLIANCE
OCAM bars are crash tested in Australia and ADR compliant. The energy-absorbing system is a patent-pending design and is among the market-leading solutions. Our investment in crash testing and certifying our bull bars means you can rely on OCAM bars for frontal protection to get you anywhere and home safely.
RECOVERY POINTS
The OCAM H-Bars include integrated recovery points which are rated to 3400kgs when used together with an equaliser strap. This extra benefit not only saves you on cost but also means there is no need to go out looking for recovery points to suit.
POWDER-COATING
In finishing, the OCAM H-Bars go through a rigorous 4-stage powder coat process. It involves:
Pre-treatment: The raw metal is cleaned and rinsed to remove all impurities. Any trace of material oil and rust is removed. It is then phosphatized, which is a metalworking process involving the use of phosphoric acid to create a protective layer over the metal.
Cathodic epoxy electrocoating: This is the global benchmark for corrosion resistance and provides the bull bar with superior adhesion and corrosion protection. It covers every corner of the product.
Prime Powder Coat: Fixes any imperfections on the surface, e.g., scratch marks, etc., and provides corrosion protection reinforcement for a long-lasting finish.
Top powder coat: Completes the bull bar with a layer of Corrosion Protection ultra-reinforcement and an excellent smooth surface finish.
HOW STRONG ARE OCAM H-BARS?
With strength and reliability in mind, the design features of the OCAM H-Bars ensure you can have peace of mind when traveling on or off-road throughout Australia. The bar is 100% welded top and bottom. The steel thickness is 2.5mm and reinforcement plates are used on the underside unlike many others to guarantee additional strength!
DELUXE VALUE
All OCAM H-Bars are equipped with LED parking and fog lights at no additional cost! They are winch compatible and include a number plate swivel mount.
FEATURES:
- Complete factory bumper bar replacement
- Modern and market-leading energy absorber system (Patent-Pending)
- Winch compatible - perfect for off-road use
- Heavy-duty steel construction for optimum strength
- The latest design in LED fog and park lights
- SRS airbag tested and certified in Australia (ADR approved)
- High-grade black e-powder coat for long-lasting protection against rust and ultimate-look finish
- Provision for mounting LED lights
- 2 x integrated recovery points, rated to 1700 kgs each. Total 3400 kgs using equaliser strap
- Number-plate swivel bracket
- Complete mounting kit with instructions.
FITTING
We offer a complete fitting service at all OCAM locations. Our dealer network across Australia is growing and we now offer a fitting service in various regions too. If you'd like a quote to include fitting, please be in touch. Just let us know your postcode, suburb, and which accessories you'd like fitted up. We'll confirm pricing for you asap.
* If you're based in an area where we don't have a fitting arrangement in place as yet, we welcome working with you to locate a suitable fitter.
PICK UP & PHONE ENQUIRIES WELCOME
Specifications
|
||
Material | Steel | |
Bar thickness | 2.5mm | |
Underbody protection plates | YES - Centre piece | |
COMPATIBILITY: | ||
OE parking sensor | YES | |
Headlight washer | NO | |
Winch compatible | YES | |
High lift jacking points | NO | |
Recovery-points | YES - 1700kgs x 2. Total 3400kgs using equaliser strap. | |
LIGHTING | ||
LED fog lights | YES | |
LED parker lights | YES | |
SAFETY | ||
Airbag compatible | YES | |
INSTALLATION | ||
Mounting hardware | YES | |
Instructions | YES |
SKU | BBH-Hilux-21 |
Brand | OCAM |
Shipping Weight | 50.000000kg |
Shipping Width | 0.600m |
Shipping Height | 0.600m |
Shipping Length | 2.000m |
Shipping Cubic | 0.720000000m3 |
